About Quectel User Experience(UX) and Product Survey

Niki.Liu-Q · August 12, 2025, 5:49am

First of all, thank you very much for choosing Quectel.

In order to improve our customer service, we kindly invite you to participate the survey of user experience when using Quectel products.
We Value Your Opinion!

How to participate:

Click the “UX Survey” button in the lower right corner of trighthe forum to complete the survey.
Click the questionnaire link in the post to complete the survey.
Scan the QR code on the poster to complete the survey.

Survey Link:移远问卷-QuecShow

SHYAM · September 4, 2025, 6:06am

HI, we need support to reset or reprogram the stop working modules. around we are using 8000 modules from that we have 200 defective which are network not connecting. we are looking firmware along with flash tools.

Niki.Liu-Q · September 5, 2025, 5:25am

hello, @SHYAM could you tell us you current firmware version,and details of the issue, i will loop the moderator to support you, thanks~

SHYAM · September 5, 2025, 12:55pm

EC25CGAR06A09M1G the issue for all sim not deduct.

SHYAM · September 6, 2025, 8:55am

@NikiWe have successfully flashed 40 out of 200 units with EC25-EC modules using firmware version EC25ECGAR06A16M1G, and these units are functioning correctly.

However, we are facing a serious issue with the remaining units. These modules are not detecting the SIM even after flashing the same firmware.

SHYAM · September 7, 2025, 7:52am

Also we are finding more two types of issues during the flashing process of the EC25-EC1 modem:

Only COM Port 11 is Detected:
During flashing, the system only shows COM port 11. No other expected COM ports appear after flashing also same.
Module Not Powering On – No COM Port Displayed:
In some cases, the module does not power on at all, and consequently, no COM port is displayed in the flashing tools.

Niki.Liu-Q · September 8, 2025, 1:26am

@AnnaLiu Hi Anna, could you please help to support this issue? Many thanks~

AnnaLiu · September 8, 2025, 11:41am

hi，
Sorry for the late reply.
May I ask if the current module can still send AT commands? Could you please provide detailed version information? Use the command to check. Is the current problem with the module caused by the firmware update? If you can send the AT command, please execute “at+cfun?”. Check the status.

Thanks

SHYAM · September 8, 2025, 12:33pm

[2025-09-08 05:31:07:209_R:] AT+CPIN?
[2025-09-08 05:31:07:246_R:] +CME ERROR: SIM not inserted

[2025-09-08 05:32:01:665_S:] AT+QGMR
[2025-09-08 05:32:01:680_R:] AT+QGMR
[2025-09-08 05:32:01:696_R:] EC25ECGAR06A16M1G_20.300.20.300
[2025-09-08 05:32:01:696_R:] OK

SHYAM · September 8, 2025, 1:25pm

[2025-09-08 05:34:22:825_R:] at+cfun
[2025-09-08 05:34:22:847_R:] ERROR

[2025-09-08 05:38:39:259_S:] AT+CFUN=0
[2025-09-08 05:38:39:265_R:] AT+CFUN=0
[2025-09-08 05:38:39:498_R:] OK

SHYAM · September 10, 2025, 5:05am

Dear Team,

Kindly review the report below and consider the issue that has been highlighted.
Please let me know if any further information is required.

/* Use ATI to get module information of Manufacturer ID, Device module and Firmware version */
[2025-09-09 22:00:59:867_S:] ATI
[2025-09-09 22:00:59:883_R:] ATI

[2025-09-09 22:00:59:883_R:] Quectel
[2025-09-09 22:00:59:883_R:] EC25
[2025-09-09 22:00:59:883_R:] Revision: EC25ECGAR06A16M1G

[2025-09-09 22:00:59:883_R:] OK

/* Use AT+GSN to query the IMEI of module */
[2025-09-09 22:00:59:898_S:] AT+GSN
[2025-09-09 22:00:59:914_R:] AT+GSN

[2025-09-09 22:00:59:930_R:] 862757054771672

[2025-09-09 22:00:59:930_R:] OK
[2025-09-09 22:00:59:930_S:] ATI
[2025-09-09 22:00:59:945_R:] ATI

[2025-09-09 22:00:59:945_R:] Quectel
[2025-09-09 22:00:59:945_R:] EC25
[2025-09-09 22:00:59:945_R:] Revision: EC25ECGAR06A16M1G

[2025-09-09 22:00:59:945_R:] OK
[2025-09-09 22:00:59:967_S:] AT+QURCCFG=“URCPORT”,“usbat”
[2025-09-09 22:00:59:967_R:] AT+QURCCFG=“URCPORT”,“usbat”

[2025-09-09 22:00:59:967_R:] OK

/* Use AT+CPIN? to query the SIM card status : SIM card inserted or not, locked or unlocked */
[2025-09-09 22:00:59:999_S:] AT+CPIN?
[2025-09-09 22:01:00:014_R:] AT+CPIN?

[2025-09-09 22:01:00:030_R:] +CME ERROR: SIM not inserted

/* Make sure SIM card is unlocked */

/* Use AT+CPIN? to query the SIM card status : SIM card inserted or not, locked or unlocked */
[2025-09-09 22:01:03:385_S:] AT+CPIN?
[2025-09-09 22:01:03:409_R:] AT+CPIN?

[2025-09-09 22:01:03:438_R:] +CME ERROR: SIM not inserted

/* Make sure SIM card is unlocked */

SHYAM · September 10, 2025, 7:51am

dear team, please check the below report & give us solution.

/* Use AT+CPIN? to query the SIM card status : SIM card inserted or not, locked or unlocked */
[2025-09-10 00:47:52:369_S:] AT+CPIN?
[2025-09-10 00:47:52:387_R:] AT+CPIN?

[2025-09-10 00:47:52:397_R:] +CPIN: READY

[2025-09-10 00:47:52:397_R:] OK

/* Use AT+CIMI to query the IMSI of SIM card */
[2025-09-10 00:47:52:427_S:] AT+CIMI
[2025-09-10 00:47:52:438_R:] AT+CIMI

[2025-09-10 00:47:52:453_R:] 901280029243604

[2025-09-10 00:47:52:453_R:] OK

/* Use AT+QCCID to query ICCID number of SIM card */
[2025-09-10 00:47:52:487_S:] AT+QCCID
[2025-09-10 00:47:52:507_R:] AT+QCCID

[2025-09-10 00:47:52:517_R:] +QCCID: 89882390000195277259

[2025-09-10 00:47:52:517_R:] OK

/* Use AT+CSQ to query current signal quality */
[2025-09-10 00:47:52:538_S:] AT+CSQ
[2025-09-10 00:47:52:553_R:] AT+CSQ

[2025-09-10 00:47:52:562_R:] +CSQ: 31,99

[2025-09-10 00:47:52:562_R:] OK

/* Use AT+CREG? /AT+CGREG? to query the network registration status. */
[2025-09-10 00:47:52:587_S:] AT+CREG?
[2025-09-10 00:47:52:597_R:] AT+CREG?

[2025-09-10 00:47:52:607_R:] +CREG: 0,3

[2025-09-10 00:47:52:607_R:] OK
[2025-09-10 00:47:52:619_S:] AT+CGREG?
[2025-09-10 00:47:52:636_R:] AT+CGREG?

[2025-09-10 00:47:52:636_R:] +CGREG: 0,3

[2025-09-10 00:47:52:636_R:] OK

/* Use AT+CREG? /AT+CGREG? to query the network registration status. */
[2025-09-10 00:47:53:653_S:] AT+CREG?
[2025-09-10 00:47:53:670_R:] AT+CREG?

[2025-09-10 00:47:53:670_R:] +CREG: 0,3

[2025-09-10 00:47:53:670_R:] OK
[2025-09-10 00:47:53:686_S:] AT+CGREG?
[2025-09-10 00:47:53:686_R:] AT+CGREG?

[2025-09-10 00:47:53:686_R:] +CGREG: 0,3

[2025-09-10 00:47:53:686_R:] OK

/* Use AT+CREG? /AT+CGREG? to query the network registration status. */
[2025-09-10 00:47:54:719_S:] AT+CREG?
[2025-09-10 00:47:54:735_R:] AT+CREG?

[2025-09-10 00:47:54:736_R:] +CREG: 0,3

[2025-09-10 00:47:54:736_R:] OK
[2025-09-10 00:47:54:753_S:] AT+CGREG?
[2025-09-10 00:47:54:774_R:] AT+CGREG?

[2025-09-10 00:47:54:774_R:] +CGREG: 0,3

[2025-09-10 00:47:54:774_R:] OK

/* Use AT+CREG? /AT+CGREG? to query the network registration status. */
[2025-09-10 00:47:55:809_S:] AT+CREG?
[2025-09-10 00:47:55:837_R:] AT+CREG?

[2025-09-10 00:47:55:837_R:] +CREG: 0,3

[2025-09-10 00:47:55:837_R:] OK
[2025-09-10 00:47:55:870_S:] AT+CGREG?
[2025-09-10 00:47:55:870_R:] AT+CGREG?

[2025-09-10 00:47:55:886_R:] +CGREG: 0,3

[2025-09-10 00:47:55:886_R:] OK

/* Use AT+CREG? /AT+CGREG? to query the network registration status. */
[2025-09-10 00:47:56:920_S:] AT+CREG?
[2025-09-10 00:47:56:953_R:] AT+CREG?

[2025-09-10 00:47:56:969_R:] +CREG: 0,3

[2025-09-10 00:47:56:969_R:] OK
[2025-09-10 00:47:56:986_S:] AT+CGREG?
[2025-09-10 00:47:56:986_R:] AT+CGREG?

[2025-09-10 00:47:57:003_R:] +CGREG: 0,3

[2025-09-10 00:47:57:003_R:] OK

/* Make sure the Antenna is connected and the network is normal */

AnnaLiu · September 10, 2025, 10:59am

hi，
From the current log, it appears that the module registration was rejected.
[2025-09-10 00:47:55:870_S:] AT+CGREG?
[2025-09-10 00:47:55:870_R:] AT+CGREG?

[2025-09-10 00:47:55:886_R:] +CGREG: 0,3

[2025-09-10 00:47:55:886_R:] OK
Next step:

Please check the following AT command. Confirm whether the APN settings are correct.
AT+CGDCONT?
May I ask if you have previously retrieved the QXDM logs?

SHYAM · September 10, 2025, 3:46pm

/* Make sure SIM card is unlocked */
[2025-09-10 08:36:32:066_S:] AT+CGDCONT?
[2025-09-10 08:36:32:066_R:] AT+CGDCONT?

[2025-09-10 08:36:32:082_R:] +CGDCONT: 1,“IP”,“mow3.vodafone.com.qa”,“0.0.0.0”,0,0,0,0

[2025-09-10 08:36:32:082_R:] OK

AnnaLiu · September 29, 2025, 1:36am

Although there is an APN, the IP has not been obtained. So the registration was rejected.

SHYAM · October 31, 2025, 4:14pm

then what is next steep?

SHYAM · November 3, 2025, 5:18am

@AnnaLiu can you send me EC25-EUX latest firmware.

jolden · November 10, 2025, 1:05am

Hi, thanks for sharing the survey info. We really appreciate the support from Quectel. We’re also facing some issues with a few modules not connecting to the network. It would be great if the team could share firmware files or tools to help us reset or reprogram the defective ones.
